AXC 3050
130
PHOENIX CONTACT 8686_en_01
Supply voltages UL
PROFINET BF-C, BF-D, SF
Other Ready to operate, overtemperature
Diagnostics and status indicators
IEC 61131 runtime system
Programming system PC Worx
Processing speed 3 ms (1 k mix instructions)
1 µs (1 k bit instructions)
Shortest cycle time (for cyclic task) 1 ms
Program memory 4 Mbyte
Mass storage 8 Mbyte
Retentive mass storage 128 kbyte
Number of data blocks Depends on mass storage
Number of control tasks 16
Number of timers, counters Depends on mass storage
Parameterization memory
Integrated
Plug-in, SD card
32 Mbyte flash memory
Max. 2 Gbyte, depending on storage medium (typ. 1,000,000 write access
operations per sector), see Section “Accessories” on page 132
Please note that the number of write access operations to the parameterization memory is limited.
Realtime clock
Accuracy +/- 1 s /day at 25°C
Power reserve Typ. 10 days (the buffer time of the clock depends on the ambient tempera-
ture of the controller).
If the AXC 3050 is not supplied with voltage for longer than this time, we rec-
ommend setting the time via SNTP.
Protection against voltage failure
Bridging time in the event of voltage interruptions 200 ms: 150 ms for backing up retain data (assigned by system) + 50 ms for
executing event task (to be parameterized by user)
Ambient conditions
Ambient temperature (operation) -25°C to +60°C (up to 2000 m above sea level)
-25°C to +55°C (up to 3000 m above sea level)
(Mounting position: wall mounting on horizontal DIN rail)
Permissible temperature (storage/transport) -40°C to +85°C
Permissible humidity (operation/storage/transport) 5% to 95% (non-condensing)
Permissible air pressure (operation) 70 kPa to 106 kPa (up to 3000 m above sea level)
Permissible air pressure (storage/transport) 58 kPa to 106 kPa (up to 4500 m above sea level)
Degree of protection IP20
Protection class III, IEC 61140, EN 61140, VDE 0140-1
Mounting position Horizontal
