The AXC 3050 controller under PC Worx
8686_en_01 PHOENIX CONTACT 89
STATUS output
(ERROR = TRUE)
The function blocks are only processed as long as the AXC 3050 controller is in the RUN
state.
When the controller goes from the RUN state to the STOP state, the current counter status
is saved. As soon as the controller returns to the RUN state, the counting process is con-
tinued based on the saved counter status.
Table 4-9 Status values of the STATUS output (ERROR = TRUE)
Value Status
0x01 MODE > 0x08
The value at the MODE input is invalid.
0x02 MODE > 0x04
The value at the EDGE input is invalid.
0x10 Invalid instance. An attempt was made to use more than one instance
of the function block.
If several errors are present, combinations of the status values are output.
