The AXC 3050 controller under PC Worx

8686_en_01 PHOENIX CONTACT 91

0x03 Clock Direction – –

Counter with external clock and counting di-

rection preset

0x04 Clock Direction Reset * –

Counter with external clock, counting direc-

tion preset, and reset function

0x05 Clock Direction Reset * Enable

Counter with external clock, counting direc-

tion preset, reset function, and counting pro-

cess enable

0x06

Clock,

counting up

Clock,

counting

down

––

Up counter or down counter

0x07

Clock,

counting up

Clock,

counting

down

Reset * –

Up counter or down counter with reset func-

tion

0x08

Clock,

counting up

Clock,

counting

down

Reset * Enable

Up counter or down counter with reset func-

tion and counting process enable

* The signal at the RESET input of the function block is ORed to the signal of the assigned Axioline I/O module input for

internal processing.

Table 4-10 Counter operating modes

MODE

[hex]

CNT1_F1 or

CNT2_F1

CNT1_F2 or

CNT2_F2

CNT1_Reset

CNT2_Reset

CNT1_Enable

CNT2_Enable

Counter operating mode

Assigned to any input from the connected Axioline F

local bus

The DIR input of the function block

is inactive in this operating mode.

The DIR input of the function block

is inactive in this operating mode.

The DIR and ENABLE inputs of the

function block are inactive in this

operating mode.

The DIR input of the function block

is inactive in this operating mode.

The DIR input of the function block

is inactive in this operating mode.

The DIR and ENABLE inputs of the

function block are inactive in this

operating mode.
