Message in the display Error/cause Description/measure
Icon Text
OVR
TIMEOUT
Override has elapsed.
RES ABORT The user can cancel the restoring of
the configuration.
When the restoring was cancelled, in
can be performed again or a new
configuration can be created in
PSENscan Configurator.
Follow the instructions in Restore
configuration [ 111].
RES IN PRO-
GRESS
The configuration in the safety laser
scanner is changed to the configura-
tion in the memory module.
Wait until the change of the configur-
ation is complete.
RES SHUT-
OFF
The rest condition of the safety laser
scanner has been deactivated.
RES VALIDA-
TION
The restoring of the configuration in
the safety laser scanner is checked.
After the check is complete, you
must confirm whether the restore
was successful.
Wait until the check of the configura-
tion is complete.
Follow the instructions in Restore
configuration [ 111].
RESTORE
DONE
The configuration was restored suc-
cessfully.
SHUT-OFF The rest condition of the safety laser
scanner has been activated.
WAITING
CONF
The safety laser scanner waits for a
configuration (e.g. after restoring a
configuration).
Configure the safety laser scanner
(see Configuration of
zones [ 88]).
WR FAILED Calibration of the new PSEN sc has
failed.
Start the calibration of the new
PSENschead again or exchange
the PSENschead [ 119].
