Overview
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 11
Legend
State OSSD 11/12
State OSSD 21/22
State OSSD 31/32 or warning zone 2
Status warning zone 1
Status interlock
Detailed description of the LEDs:
Icon State
= LED on
= LED off
Meaning
OSSD 11/12
Green
No object detected in
safety zone 1
Red
Object detected in safety
zone 1
OSSD 21/22
Green
No object detected in
safety zone 2
Red
Object detected in safety
zone 2
