Overview
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 12
Icon State
= LED on
= LED off
Meaning
OSSD 31/32
or
Green
No object detected in
safety zone 3
Red
Object detected in safety
zone 3
Warning zone 2 No object detected in
warning zone 2
Yellow
Object detected in warn-
ing zone 2
Warning zone 1 No object detected in
warning zone 1
Yellow
Object detected in warn-
ing zone 1
Locking
yellow and
lights up red
No object detected in
safety zone,
PSEN sc M 3.0/5.5 08-17
series waits for manual
restart
and
lights up green
No object detected in
safety zone,
PSEN sc M 3.0/5.5 08-17
series is ready for opera-
tion
and
lights up red
Object detected in safety
zone,
PSEN sc M 3.0/5.5 08-17
series in OFF state
