Project configuration
Operating Manual PSEN sc M 3.0/5.5 08-17
1005387-EN-05
| 40
[2]
[3]
[4]
[1]
[1]
Legend
[1] Danger zone with fence
[2] Safeguarded area
[3] Not safeguarded area - safeguard against stepping behind
[4] Safety laser scanner
