Pitco SSHLV Series - Replacing the Relay Board and Paper

Pitco SSHLV (ROV) Gas Fryers
7.1 Replacing the Relay Board and Paper
1. Remove the front panel. See “Removing the
Controller Front Panel Bezel” in Section 5.1.
2. Disconnect all connections from the board.
3. Remove the seven (7) screws, which hold
down the relay board, using a small flathead
screwdriver.
4. Remove the relay board and flip it over.
5. Remove the existing insulation paper and
replace with a new insulator paper.
NOTE
Make sure the insulation paper doesn’t have
puncture marks in it.
6. Reinstall by following steps 1 through 5 in
reverse.
L22-392 R1 22
