Pitco SSHLV Series - Replacing the Return Valve

Pitco SSHLV (ROV) Gas Fryers
19 Replacing the Return Valve
!
WARNING
!
DO NOT remove fry vat or drain fittings before all oil is drained from the tank. Serious injury will result
from slipping, falling or contact with hot liquids causing property damage, injurious severe burns
and/or death.
1. Remove all connections from the 3-way
return valve using a 1/16 inch wrench.
2. Remove the cotter pin on return valve using
needle-nose pliers.
3. Replace the return valve by following steps 1
through 2 in reverse, replacing the cotter pin if
necessary.
NOTE
Thread sealant is not required for these fittings.
.
L22-392 Rev 1 41
