Pitco SSHLV (ROV) Gas Fryers
32.4 Adjusting the Magnetic Sensor
1. Make sure the sensor is approximately 3/4
inch from top of the motor to bottom of the
sensor.
2. Make sure the sensor is approximately 7 3/4
inch from top of the motor to bottom of the
sensor.
32.5 Replacing the Basket Lift Actuator
1. Cut all zip ties on the basket lift driver board.
2. Disconnect the transformer from the driver
board. See “Wiring Diagram – Basket Lifts” in
Section 36.10.
3. Disconnect the upper and lower limit
connections on the basket lift driver board.
4. Remove the two (2) bolts, which hold the
actuator, using a 3/16 inch Allen key.
L22-392 Rev 1 70
