Pitco SSHLV (ROV) Gas Fryers
8.4 Checking the Resistance of the Hi-Limit
If the Hi-limit is suspect, allow the fryer to cool to
room temperature before performing this test.
The high limit will remain OPEN until the oil
temperature has dropped below the tripping
1. Unplug the Hi-Limit connection.
2. Connect the multimeter to the Hi-limit leads
and check the resistance.
3. If the measurement shows an open circuit
and/or greater than 0.5 ohms then the
Hi-
limit
is bad and needs to be replaced or
reset. see Section 10.
If there is a small resistance
(0.1 – 0.2 ohms) reading, the Hi-limit is
closed and ready to use, no replacement is
required.
L22-392 R1 25
