Pitco SSHLV Series - Replacing the Basket Lift Driver Board

Pitco SSHLV (ROV) Gas Fryers
32.3 Replacing the Basket Lift Driver Board
1. Remove all wires on basket lift driver board
using needle-nose pliers.
2. Remove the sensor connection using needle-
nose pliers.
3. Remove the control signal connection using
needle-nose pliers.
4. Remove the actuator power connection using
needle-nose pliers.
5. Remove the four (4) screws, which hold the
basket lift driver board, using a Phillips
screwdriver.
6. Follow steps 1 through 5 in reverse to
reinstall a new basket lift driver board.
L22-392 Rev 1 69
