Pitco SSHLV (ROV) Gas Fryers
6. Remove the two (2) screws, which hold the
SCB runner tube, using a 5/16 inch socket.
7. Remove the two (2) screws, which hold each
burner, using a 5/16 inch socket.
8. Remove the right burner(s) by sliding them
off the SCB runner tube.
9. Remove the SCB runner tube.
10. Remove the left burner(s) If you have
already removed runner tube, just remove the
left burners.
11. Reinstall the new burner(s) by following
steps 1 through 12 in reverse.
Check for gas leaks after installation or servicing
of a gas fryer. Apply a leak detection solution to
all connections and joints to ensure there are no
bubbles or leaks. Failure to check for and correct
any leaks could lead to fire and/or explosion,
property damage, injury and death.
L22-392 Rev 1 62
