User’s Manual of FGSD-1022 Series
12
1.4 Product Features
 Physical Port
FGSD-1022
 8-Port 10/100Base-TX RJ-45 interfaces
 2 10/100/1000T TP combo interfaces
 2 mini-GBIC/SFP slots, shared with Port-9 and Port-10
 Reset button for system management
 1 RS-232 male DB9 console interface for Switch basic management and setup
FGSD-1022P
 8-Port 10/100Base-TX RJ-45 with IEEE 802.3af PoE Injector
 2 10/100/1000T TP combo interfaces
 2 mini-GBIC/SFP slots, shared with Port-9 and Port-10
 Reset button for system management
 1 RS-232 male DB9 console interface for Switch basic management and setup
FGSD-1022HP
 8-Port 10/100Base-TX RJ-45 with IEEE 802.3af / IEEE 802.3at PoE Injector
 2 10/100/1000Base-T TP combo interfaces
 2 mini-GBIC/SFP slots, shared with Port-9 and Port-10
 Reset button for system management
 1 RS-232 male DB9 console interface for Switch basic management and setup
 Layer 2 Features
 Prevents packet loss Flow Control:
 IEEE 802.3x PAUSE frame Flow Control for Full-Duplex mode
 Back-Pressure Flow Control in Half-Duplex mode
 High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates
erroneous packets to optimize the network bandwidth
 8K MAC Address Table, automatic source address learning and ageing
 Support VLAN:
 IEEE 802.1Q Tag-Based VLAN
 Port-Based VLAN
 Q-in-Q tunneling (Double Tag VLAN)
 GVRP for dynamic VLAN Management
 Private VLAN Edge (PVE / Protect Port )
 Supports Link Aggregation
 Up to 13 Trunk groups
 Up to 8 ports per trunk group with 1.6Gbps bandwidth (Full Duplex mode)
 IEEE 802.3ad LACP (Link Aggregation Control Protocol)
 Cisco ether-Channel (Static Trunk)
 Support Spanning Tree Protocol:
 STP, IEEE 802.1D (Classic Spanning Tree Protocol)
 MSTP, IEEE 802.1s (Multiple Spanning Tree Protocol, spanning tree by VLAN)
