User’s Manual of FGSD-1022 Series
208
6.18.4 Configure PoE -- Port
poe enable
Description:
Enabling or disabling the port POE injects function.
Command Level:
Global Configuration
Syntax:
poe enable [<port-list>]
[no] poe enable [<port-list>]
Parameters:
<port-list> specifies the ports to be set. If not entered, all ports are set.
Example:
Switch(config)# poe enable 1
Switch(config)# show poe status 1
Port Admin Oper
Power
Mode
Priority Power Limit[W]
Current Consumption
[W]
Current[mA] Device Class
Port1 Enable on 802.3at Low 15.4 13.4 279 0
Switch(config)# no poe enable 1
Switch(config)# show poe status 1
Port Admin Oper
Power
Mode
Priority Power Limit[W]
Current Consumption
[W]
Current[mA] Device Class
Port1
Disable
on 802.3at High 15.4 13.4 279 0
