User’s Manual of FGSD-1022 Series
15
1.5 Product Specification
Product FGSD-1022 FGSD-1022P FGSD-1022HP
Hardware Specification
10/100Mbps Copper Ports
8 10/ 100Base-TX RJ-45
Auto-MDI/MDI-X ports
8 10/ 100Base-TX RJ-45
Auto-MDI/MDI-X ports
8 10/ 100Base-TX RJ-45
Auto-MDI/MDI-X ports
1000Mbps Copper Ports
2 10/100/1000Base-T RJ-45 port
SFP/mini-GBIC Slots
2 SFP interfaces, shared with Port-9 and Port-10
Switch Architecture
Store-and-Forward
Switch Fabric
5.6Gbps / non-blocking
Switch Throughput
4.16Mpps@64Bytes
Address Table
8K entries
Share Data Buffer
2Mbits
Flash
4Mbytes
DRAM
32Mbytes
Maximum Frame Size
9K Bytes
Flow Control
Back pressure for Half-Duplex
IEEE 802.3x Pause Frame for Full-Duplex
LED
Power (Green)
Link/Activity (Green)
10/100 LNK / ACT(Orange)
1000 LNK / ACT(Green)
10/100 LNK / ACT(Orange)
Power (Green)
Link/Activity (Green)
PoE In-Use (Orange)
1000 LNK / ACT(Green)
10/100 LNK / ACT(Orange)
Dimensions ( W x D x H)
330 x 155 x 44 mm,
1U height
330 x 155 x 44 mm,
1U height
Weight
1.2kg 1.6kg 1.74kg
Power Requirement
100~240V AC, 50-60 Hz
Power Consumption
16 Watts (Full load) 140 Watts (Full PoE Load) 170 Watts (Full PoE Load)
Operating Temperature
Standard: 0 ~ 50 Degree C
Operating Humidity
20% to 95% (Non-condensing)
Storage Temperature
-10 Degree C ~ 70 Degree C
Layer 2 Functions
Management Interface
Console, Telnet, Web Browser, SSL, SNMP v1, v2c, v3
Port Configuration
Port disable/enable.
Auto-negotiation 10/100Mbps full and half duplex mode selection.
Flow Control disable / enable.
Bandwidth control and broadcast storm filter on each port.
