User’s Manual of FGSD-1022 Series
Work ports:
This column field allows the user to type in the total number of active port up to
four. With LACP static trunk group, e.g. you assign four ports to be the
members of a trunk group whose work ports column field is set as two; the
exceed ports are standby/redundant ports and can be aggregated if working
ports fail. If it is a static trunk group (non-LACP), the number of work ports must
equal the total number of group member ports.
Please notice that a trunk group, including member ports split between two switches, has to enable the
LACP function of the two switches.
4.6.2 Aggregator Information
When you had setup the LACP aggregator, you will see relation information in here.
LACP disabled
Having set up the aggregator setting with LACP disabled, you will see the local static trunk group information on the tab of
Aggregator Information.
Figure 4-6-2: Assigning 2 ports to a trunk group with LACP disabled
101
