User’s Manual of FGSD-1022 Series
9
1. Introduction
The PLANET Layer 2 Managed Switch series - FGSD-1022, FGSD-1022P and FGSD-1022HP are multiple 10/100Mbps
ports Ethernet Switched with Gigabit TP/SFP fiber optical combo connective ability and robust layer 2 features; the
description of these models as below:
FGSD-1022 :
8-Port 10/100Base-TX + 2-Port Gigabit TP/SFP Combo Managed Switch
FGSD-1022P :
8-Port 10/100Base-TX + 2-Port Gigabit TP/ SFP Managed PoE Switch
FGSD-1022HP :
8-Port 10/100Base-TX + 2-Port Gigabit TP/ SFP Managed 802.3at PoE Switch
Terms of “Managed Switch” means the Switches mentioned titled in the cover page of this User’s manual, i.e.FGSD-1022,
FGSD-1022P and FGSD-1022HP.
1.1 Package Contents
Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:
Check the contents of your package for following parts:
The Managed Switch
x1
User’s Manual CD
x1
Quick Installation Guide
x1
19” Rack mount Accessory Kit
x1
Power Cord
x1
Rubber Feet
X4
RS-232 DB9 Male Console Cable
x1
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the
original packing material, and use them against to repack the product in case there is a need to return it to us for repair.
