User’s Manual of FGSD-1022 Series
4. Select on the firmware then click “Upload”, the Software Upload Progress would show the file upload status.
Firmware upgrade needs several minutes. Please wait a while, and then manually
refresh the webpage.
4.2.5 Configuration Backup
4.2.5.1 TFTP Restore Configuration
You can restore a previous backup configuration from the TFTP server to recover the settings. Before doing that, you must
locate the image file on the TFTP server first and the Managed Switch will download back the flash image.
Figure 4-2-14: Configuration Restore interface
The page includes the following fields:
Object Description
TFTP Server IP Address:
Type in the TFTP server IP.
Restore File Name:
Type in the correct file name for restoring.
54
