User’s Manual of FGSD-1022 Series
4.13.3 PoE Schedule
PoE Schedule allows user to scheduling PoE power supply. User has to define when system supplies PoE power from a
time table as following screen shot, and there are 4 profiles totally for user applying PoE power supply strategy. The web
screen in Figure 4-13-3 appears.
Figure 4-13-3: PoE Schedule Configure Interface
The page includes the following fields:
Object Description
Profile:
Power Over Ethernet Schedule offers 4 profiles totally for user to define time
table.
00 - 23
Allows system to supply PoE power from 00:00 to 23:00, the unit is hour.
Sun - Sat
Allows system to supply PoE power from Sunday to Saturday.
Apply:
Click Apply button to save configuratipon.
After we finished profile setting, and then we have to get back to PoE Configuration WEB page, and select “Schedule”
option from PoE function then we can select profile from PoE Schedule which we want to apply to the PoE port. The web
screen in Figure 4-13-4 appears.
Please be noticed before we use PoE schedule function that we must set up SNTP on the switch first and make sure the
SNTP has been worked well.
144
