User’s Manual of FGSD-1022 Series
195
6.16 Access Control List
Packets can be forwarded or dropped by ACL rules include Ipv4 or non-Ipv4. The Managed Switch can be used to block
packets by maintaining a table of packet fragments indexed by source and destination IP address, protocol, and so on
6.16.1 Ipv4 ACL commands
no acl
Description:
Delete ACL group.
Syntax:
no acl <1-220>
Parameters:
<1-220> specifies the group id.
e.g. no acl 1
no acl count
Description:
Reset the Acl group count.
Syntax:
no acl count <GroupId>
Parameters:
GroupId: <1-220> specifies the group id.
show acl
Description:
Show ACL group information.
Syntax:
show acl [<1-220>]
Parameters:
<1-220> specifies the group id, null means all valid groups.
e.g.
Switch(config)# show acl 1
Group Id : 1
-------------------------------
A
ction : Permit
Rules:
Vlan ID : An
y
IP Fragement : Uncheck
Src IP Address : Any
Dst IP Address : Any
L4 Protocol : Any
