User’s Manual of FGSD-1022 Series
Consumption [W] It shows the PoE device current watt.
Power Limit It can limit the port PoE supply watts.
Per port maximum value must less than 15.4 watts, total ports values must
less than the Power Reservation value.
Once power overload detected, the port will auto shut down and keep on
detection mode until PD’s power consumption lower than the power limit value.
For FGSD-1022P, the total PoE power reservation from Port-1~8 is up to 180W.
For FGSD-1022HP, the total PoE power reservation from Port-1~8 is up to 150W.
As following provides FGSD-1022HP PoE (Power over Ethernet) Configuration and PoE output status of PoE Switch,
screen in Figure 4-13-2 appears.
Figure 4-13-2: PoE Configuration
141
