User’s Manual of IGSW-24040T
Figure 4-10-4 ACL Ports Configuration page screenshot
The page includes the following fields:
Object Description
 Port
The logical port for the settings contained in the same row.
 Policy ID
Select the policy to apply to this port. The allowed values are 1 through 8. The
default value is 1.
 Action
Select whether forwarding is permitted ("Permit") or denied ("Deny"). The default
value is "Permit".
 Rate Limiter ID
Select which rate limiter to apply to this port. The allowed values are Disabled
or the values 1 through 15. The default value is "Disabled".
 Port Copy
Select which port frames are copied to. The allowed values are Disabled or a
specific port number. The default value is "Disabled".
203
