User’s Manual of IGSW-24040T
DHCP relay information operation mode enabled. Possible policies are:
Replace: Replace the original relay information when receive a DHCP message
that already contains it.
Keep: Keep the original relay information when receive a DHCP message that
already contains it.
Drop: Drop the package when receive a DHCP message that already contains
relay information.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.9 DHCP Relay Statistics
This page provides statistics for DHCP relay. The DHCP Relay Statistics screen in Figure 4-2-12 appears.
Figure 4-2-12 DHCP Relay Statistics Page Screenshot
The page includes the following fields:
Server Statistics
Object Description
 Transmit to Server
The packets number that relayed from client to server.
 Transmit Error
The packets number that packet of error sent packets to client.
 Receive form Server
The packets number that received packets from server.
 Receive Missing Agent
Option
The packets number that received packets without agent information options.
 Receive Missing
Circuit ID
The packets number that received packets which the Circuit ID option was
missing.
62
