User’s Manual of IGSW-24040T
Server.
- Voice VLAN : Voice VLAN is a VLAN configured specially for voice traffic
typically originating from IP phones.
- MVR : MVR is used to eliminate the need to duplicate multicast traffic for
subscribers in each VLAN. Multicast traffic for all channels is sent only on a
single (multicast) VLAN.
- MSTP : The 802.1s Multiple Spanning Tree protocol (MSTP) uses VLANs to
create multiple spanning trees in a network, which significantly improves
network resource utilization while maintaining a loop-free environment.
Buttons
: Select VLAN Users from this drop down list.
Auto-refresh
: Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
4.6.7 VLAN Port Status for User Static
This page provides VLAN Port Staus. The VLAN Port Status for User Static screen in Figure 4-6-5 appears.
121
