User’s Manual of IGSW-24040T
1.4 Product Features
 Physical Port
IGSW-24040T
 24-Port 10/100/1000Base-T Gigabit Ethernet RJ-45
 4 100/1000Base-X SFP slots, shared with Port-21 to Port-24
 RS-232 DB9 console interface for Switch basic management and setup
 Industrial Conformance
 36 to 72V DC, redundant power with polarity reverse protect function
 -40 to 75 Degree C operating temperature
 IP-30 metal case, 19-inch Rack-mountable
 Relay alarm for port breakdown, power failure
 Supports 6000 VDC Ethernet ESD protection
 Free fall, Shock and Vibration Stability
 FAN Less Design
 Layer 2 Features
■ Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
■ High performance of Store-and-Forward architecture, broadcast storm control and runt/CRC filtering eliminates
erroneous packets to optimize the network bandwidth
■ Storm Control support:
 Broadcast / Multicast / Unknown-Unicast
■ Support VLAN
 IEEE 802.1Q Tagged VLAN
 Up to 255 VLANs groups, out of 4094 VLAN IDs
 Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
 Private VLAN Edge (PVE)
 Voice VLAN
■ Support Spanning Tree Protocol
 STP, IEEE 802.1D Spanning Tree Protocol
 RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
 MSTP, IEEE 802.1s Multiple Spanning Tree Protocol, spanning tree by VLAN
 BPDU Guard
■ Support Link Aggregation
 802.3ad Link Aggregation Control Protocol (LACP)
 Cisco ether-channel (Static Trunk)
 Maximum 12 trunk groups, up to 16 ports per trunk group
 Up to 32Gbps bandwidth(Duplex Mode)
■ Provide Port Mirror (many-to-1)
