User’s Manual of IGSW-24040T
different server is counted as a
Request as well as a timeout.
This section contains information about the state of the server and the latest round-trip
time.
Name RFC4670 Name Description
State
- Shows the state of the server. It takes one of
the following values:
Disabled: The selected server is disabled.
Not Ready: The server is enabled, but IP
communication is not yet up and running.
Ready: The server is enabled, IP
communication is up and run, and the RADIUS
module is ready to accept accounting
attempts.
Dead (X seconds left): Accounting attempts
were made to this server, but it did not reply
within the configured timeout. The server has
temporarily been disabled, but will get
re-enabled when the dead-time expires. The
number of seconds left before this occurs is
displayed in parentheses. This state is only
reachable when more than one server is
enabled.
 Other Info
Round-Trip
Time
radiusAccClientExtRo
undTripTime
The time interval (measured in milliseconds)
between the most recent Response and the
Request that matched it from the RADIUS
accounting server. The granularity of this
measurement is 100 ms. A value of 0 ms
indicates that there hasn't been round-trip
communication with the server yet.
4.11.9 Windows Platform RADIUS Server Configuration
Setup the RADIUS server and assign the client IP address to the Managed switch. In this case, field in the default IP Address
of the Managed Switch with 192.168.0.100. And also make sure the shared secret key is as same as the one you had set at
the Managed Switch’s 802.1x system configuration – 12345678 at this case.
240
