User’s Manual of IGSW-24040T
 Port Mode
Configuration
Specify IP Source Guard is enabled on which ports. Only when both Global Mode
and Port Mode on a given port are enabled, IP Source Guard is enabled on this
given port.
 Max Dynamic Clients
Specify the maximum number of dynamic clients can be learned on given ports.
This value can be 0, 1, 2 and unlimited. If the port mode is enabled and the value
of max dynamic client is equal 0, it means only allow the IP packets forwarding
that are matched in static entries on the specific port.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.12.11 IP Source Guard Static Table
This page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11 appears.
Figure 4-12-11 Static IP Source Guard Table Screen Page Screenshot
T
he page includes the following fields:
Object Description
 Delete
Check to delete the entry. It will be deleted during the next save.
 Port
The logical port for the settings.
 VLAN ID
The VLAN ID for the settings.
 IP Address
Allowed Source IP address.
 IP Mask
It can be used for calculating the allowed network with IP address.
263
