User’s Manual of IGSW-24040T
ï‚· Counter
The counter indicates the number of times the ACE was hit by a frame.
ï‚· Modification Buttons
You can modify each ACE (Access Control Entry) in the table using the following
buttons:
: Inserts a new ACE before the current row.
: Edits the ACE row.
: Moves the ACE up the list.
: Moves the ACE down the list.
: Deletes the ACE.
: The lowest plus sign adds a new entry at the bottom of the ACE listings.
Buttons
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs at regular intervals.
: Click to refresh the page; any changes made locally will be undone.
: Click to clear the counters.
: Click to remove all ACEs.
4.10.3 ACE Configuration
Configure an ACE (Access Control Entry) on this page.
An ACE consists of several parameters. These parameters vary according to the frame type that you select. First select the
ingress port for the ACE, and then select the frame type. Different parameter options are displayed depending on the frame type
that you selected. The ACE Configuration screen in Figure 4-10-3 appears.
