User’s Manual of IGSW-24040T
4.9.2.1 Set up Policy Rules
Group ports into several types which according to different QCL policies. The settings relate to the currently selected unit, as
reflected by the page header. The screen in Figure 4-9-2 appears.
Figure 4-9-2 Set up Policy Rules Page Screenshot
The page includes the following fields:
Object Description
 QCL ID
Frames that hit this QCE are set to match this specific QCL.
 Port Members
A row of radio buttons for each port is displayed for each QCL ID. To include a
port in a QCL member, click the radio button.
170
