User’s Manual of IGSW-24040T
1.5 Product Specification
Product IGSW-24040T
Hardware Specification
Copper Ports
24 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
4 1000Base-SX/LX/BX SFP interfaces, shared with Port 21 to Port 24
Compatible with 100Base-FX SFP
Console Port
1 x RS-232 DB9 serial port (115200, 8, N, 1)
Switch Processing Scheme
Store-and-Forward
Switch Throughput@64Bytes 35.7Mpps
Switch Fabric
48Gbps / non-blocking
Address Table
8K entries, automatic source address learning and ageing
Share data Buffer
1392 kilobytes
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame
10Kbytes
Reset Button
< 5 seconds: System reboot
> 10 seconds: Factory Default
Dimension (W x D x H)
440 x 200 x 44.5 mm, 1U high
Weight
2.96kg
LED
Power, Link/Act and speed per Gigabit port
Power Consumption
Max. 30 Watts / 102 BTU (AC)
Power Requirement – AC
AC 100~240V, 50/60Hz 0.75A
Power Requirement – DC
36V DC @ 0.75A, Range: -36V ~ -72V DC
ESD Protection
6KV DC
DI/DO
2 Digital Input (DI): Level 0: -30~0V
Level 1: 0~30V
Max. input current: 8mA
2 Digital Output(DO): Open collector to 30VDC, 200mA
Layer 2 Function
Port configuration
Port disable / enable
Auto-Negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable
Bandwidth control on each port
Power saving mode control
Port Status
Display each port’s speed duplex mode, link status, Flow control status.
Auto negotiation status, trunk status.
24
