User’s Manual of IGSW-24040T
63
 Receive Missing
Remote ID
The packets number that received packets which Remote ID option was missing.
 Receive Bad Circuit ID
The packets number that the Circuit ID option did not match known the circuit ID.
 Receive Bad Remote
ID
The packets number that the Remote ID option did not match the known Remote
ID.
Client Statistics
Object Description
 Transmit to Client
The packets number that relayed packets from server to client.
 Transmit Error
The packets number that error sending packets to servers.
 Receive form Client
The packets number that received packets from server.
 Receive Agent Option
The packets number that received packets with relay agent information option.
 Replace Agent Option
The packets number that replaced received packets with relay agent information
option.
 Keep Agent Optin
The packets number that keepped received packets with relay agent information
option.
 Drop Agent Option
The packets number that dropped received packets with relay agent information
option.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page; any changes made locally will be undone.
: Clear all statistics.
