GENERAL INFORMATION
1.7
MODEL: 440 PRO X..........
MODEL NUMBER: S03NX4CS.
ENGINE MODEL: S2424--4460PA4C..
ELECTRICAL CAPACITIES
Flywheel I.D. 4010629 Fuel Tank 5 Gal. (18.9 L)...... ..........
CDI Marking 4010861 Oil Tank N/A (PRE MIX 32:1)....... ............
Alternator Output 280 Watts Coolant 4 Quarts (3.78 L)... ............
Ignition Timing 12q BTDC@1750RPM in “D” CurveChaincase Oil 9 oz...... .......
.with pipe sensor unplugged
Spark Plug / Gap Champion RN-57YCC / 0.025” (0.64mm) PN 3070190...
Lights: Head 2 60High/55Low......
Tail 2@2 watts........
Brake 1@17 watts......
Voltage Regulator T1..
Electric Start N/A.......
SUSPENSION / CHASSIS CHAINCASE
Body Style PRO X Sprockets / Chain 19:43--74 P HYVO........ ...
Front Suspension PRO X Reverse N/A.. ............
IFS Shocks Walker Evans Alum IFP Brake Pads Hayes Type 81........ .........
Comp Adjust w/ Res. Chaincase Center Dist.7.92” (20.12cm.)...................
IFS Spring Rate 74/165#/in. Driveshaft Sprockets 2 Drivers-wide.... .
Front Spring Preload 3.75s Thread Adjust Brake Type Hayes.........
Front Vertical Travel 9.22s (23.42 cm.)
Rear Suspension PRO X...
Rear Travel 13.90s (35.31 cm..)........
Front Track Shock Walker Evans Alum IFP..
Comp Adjust w/ Res....................
Spring Rate 160#/in.........
Rear Track Shock Walker Evans Alum IFP..
Comp Adjust w/ Res....................
Rear Springs .347s (sq.) / 77q......
Track Type 14sx121sx1.625s (35.6 x 307.34 x 4.12cm..)........
Track Tension
11/2s (38mm) slack with 10# (4.54kg) weight 16s (40.64cm..) ahead of rear idler shaft......
OPTIONAL REAR TORSION SPRINGS
440 Pro X Rear Torsion Springs
SOFT (STD) FIRM
.347s(sq.) diameter/77q .347s(sq.) diameter/77q .359s(sq.) diameter/77q
L.H 7042159-067 L.H. 7042101-067 L.H. 7042157-067
R.H. 7042160-067 R.H 7042102-067 R.H. 7042158-067
