REAR SUSPENSION/TRACK/TRACTION
7.34
XTRA Lite Wide Hi-Fax
Xtra Lite wide hi-fax is available for ice racing applications. The part number is 5521587--309 for 2003 Pro X
suspensions. Install with the wide side to the outside of the snowmobile. These hi-fax are made with a wear mark
on the outside. When the hi-fax is wore to the wear mark line, replace the hi-fax.
Hi-Fax Removal
1. Remove suspension from machine.
NOTE: Some models may allow Hi Fax to be removed by sliding it through track windows with the suspension
mounted in the machine.
2. Remove front Hi-Fax retaining bolt.
Hi Fax Replacement
3. Use a block of wood or drift punch and a hammer to drive Hi-Fax rearward off the slide rail.
4. With Hi-Fax material at room temperature, install new Hi-Fax by reversing steps 1 - 3.
Rubber Track Clip Replacement
1. Install replacement clip and clipping tool.
NOTE: For ease of operation, the tool may be placed in a vise.
2. Tighten drive bolt against forming die until clip is formed.
Track Guide Clip Installation Tool
PN 2871041
Track Clip Removal Tool
PN 2871337
