ELECTRICAL
8.3
Twin Cylinder Fan CDI Ignition - Exploded View - Timing
440 Pro X Fan
Stator
RFI Caps
Ignition Coil
CDI System
240 Watt System
NOTE: Always verify timing of engine at room temperature only (68q F/20q C, no engine warm up) and at the
proper RPM.
Blower Housing
Stationary
Lines
Flywheel
Mark
NOTE: Acceptable variance
is usually one line on either
side of the dial indicated
blower housing stationary
line.
