STEERING / FRONT SUSPENSION
6.4
BOLD type indicates Production setting
SLED POSITION RATE SPRING #
FREE
LENGTH
SOLID
LENGTH
SHOCK # TRAVEL
SPRING
PRELOAD
MAX PRE--
LOAD
PRELOAD
DIMENTION
IFS 74/165 7042187 12.55” 4.72” 7042180 6.27” 14 Turn
s 21.8 Turns 3.75”
IFS 175 7042122
10.5” 4.25” 7042180 6.27”
120 7041699 4.00” 1.35” 7042180
6.27”
IFS 155 7042090 10.5” 4.25” 7042180
6.27”
100 7041698 4.00” 1.31” 7042180 6.
27”
IFS 195 7042092 10.5” 4.25” 7042180
6.27”
140 7041820 4.00” 1.50” 7042180 6.
27”
F/T
160 7042091 7.00” 3.00” 7042178 3.76” 2 Turns
3.4 Turns 2.88”
F/T 140 7041680 7.00” 2.75” 7042178
3.76” 2 Turns 6.9 Turns 2.88”
F/T 180 7041827 7.00” 3.25”
7042178 3.76” 2 Turns 1.3 Turns 2.88”
SLED POSITION RATE SPRING #
FREE
LENGTH
SOLID
LENGTH
SHOCK # TRAVEL
SPRING
PRELOAD
MAX PRE--
LOAD
PRELOAD
DIMENTION
IFS 90/180 7042195 13.00” 5.07” 7042183 6.27” 2 Turns
23.2 Turns 2.50”
IFS 110 7042052 12.00” 5.00” 7042183
6.27” 1 Turn 20.8 Turns 2.75”
IFS 130 7042051 12.00” 5.00” 7042183
6.27” 1 Turn 20.8 Turns 2.75”
IFS 150 7042053 12.00” 5.00” 7042183
6.27” 1 Turn 20.8 Turns 2.75”
F/T
190 7041870 7.50” 3.25” 7042205 3.74” 3 Turns
8.2 Turns 2.38”
F/T 181 7041712 7.50” 3.00” 7042205
3.74” 3 Turns 12.2 Turns 2.38”
F/T 200 7041797 7.50” 3.17”
7042205 3.74” 4 Turns 9.4 Turns 2.38”
SLED POSITION RATE SPRING #
FREE
LENGTH
SOLID
LENGTH
SHOCK # TRAVEL
SPRING
PRELOAD
MAX PRE--
LOAD
PRELOAD
DIMENTION
IFS 90/180 7042195 13.00” 5.07” 7042215 5.70” 2 Turns
31.5 Turns 2.00”
IFS 110 7042052 12.00” 5.00” 7042215
5.70” 1 Turn 20.8 Turns 2.75”
IFS 130 7042051 12.00” 5.00” 7042215
5.70” 2 Turns 20.8 Turns 2.75”
IFS 150 7042053 12.00” 5.00” 7042215
5.70” 3 Turns 20.8 Turns 2.75”
F/T
160 7041671 9.00” 3.87” 7042214 3.75” 2 Turns
19.3 Turns 1.75”
F/T 190 7041870 7.50” 3.25” 7042124
3.75” 3 Turns 8 Turns 2.38”
F/T 181 7041712 7.50” 3.00”
7042124 3.75 3 Turns 12 Turns 2.38”
F/T 200 7041797 7.50” 3.17” 7042124
3.75 3 Turns 9.3 Turns 2.38”
34.7 Turns 1.75”
600/700/800 PRO X
440 PRO X FAN
440 PRO X
17 Turns 17 Turns
MAXIMUM SPRING PRELOAD MATRIX
17 Turns 37.4 Turns 1.75”
36.8 Turns 1.75”
