STEERING / FRONT SUSPENSION
6.3
Spring Data Continued
*All springs shipped as service parts are black. You must add a suffix of “--067” to spring part number when
ordering.
Spring Part #
Length
(in)
Wire
Diameter (in)
#OfCoils
Active
Coils
Outside
Diameter (in)
Solid
Length
(in)
Spring Rate
(lb/in)
7041698 4.00 0.225 5.84 3.84 2.350 1.310 100
7041699 4.00 0.235 5.75 3.75 2.370 1.350 120
7041701 9.00 0.295 10.57 8.57 2.490 3.120 120
7041790 13.00 0.421 10.84 8.84 3.500 6.125 175
7041792 7.50 0.362 8.98 6.98 2.800 3.170 250
7041796 13.00 0.406 9.99 7.99 3.630 6.125 150
7041797 7.50 0.343 9.26 7.26 2.750 3.170 200
7041820 4.00 0.250 5.98 3.98 2.430 1.500 140
7041821 4.00 0.262 5.91 3.91 2.490 1.550 160
7041822 7.50 0.343 8.75 6.75 2.720 3.250 225
7041823 7.50 0.375 8.82 6.82 2.870 3.250 275
7041824 13.00 0.421 12.81 10.81 3.630 6.125 130
7041825 13.00 0.438 12.72 10.72 3.400 6.125 190
7041826 7.00 0.306 9.19 7.19 2.540 3.250 160
7041827 7.00 0.312 8.85 N/A 2.540 3.250 180
7041828 7.00 0.331 9.61 7.61 2.590 3.250 200
7041829 7.00 0.331 8.92 6.92 2.590 3.250 220
7041830 6.00 0.250 8.50 6.50 2.430 2.500 85
7041831 6.00 0.262 8.57 6.57 2.450 2.500 100
7041832 6.00 0.281 8.82 6.82 2.510 2.500 120
7041833 6.00 0.281 8.04 6.04 2.490 2.500 140
7041834 9.00 0.362 7.39 5.39 3.240 4.500 200
7041835 9.00 0.375 7.74 5.73 3.230 4.500 220
7041836 9.00 0.393 7.82 5.82 3.330 4.500 240
7041837 9.00 0.406 7.32 5.32 3.490 4.500 260
7041870 7.50 0.331 6.77 4.77 3.000 3.250 190
7041887 2.20 0.125 4.15 2.15 1.640 N/A 59
7041914 7.57 0.331 9.62 7.62 2.900 3.180 160
7041915 2.25 0.207 4.74 2.74 2.340 0.980 100
7041916 2.25 0.218 4.21 2.21 2.370 0.920 150
7041917 2.25 0.235 4.03 2.03 2.390 0.950 215
7041927 13.00 0.295 16.15 14.15 2.540 4.770
68--160
7041937 10.13 0.331 15.20 13.20 2.650 N/A 100--200
7041950 11.57 0.331 13.80 11.80 3.125 4.570 68--160
7042048 2.60 0.243 4.28 N/A 2.400 1.040 220
7042049 2.60 0.262 4.54 N/A 2.430 1.190 260
7042051 12.00 0.362 12.50 N/A 3.000 5.000 130
7042052 12.00 0.331 10.25 8.25 3.000 5.000 110
7042053 12.00 0.362 10.94 8.94 3.000 5.000 150
7042055 2.50 0.235 4.47 N/A 2.380 1.050 180
7042074 10.65 0.343 11.63 9.63 3.200 3.980
90--180
7042090 10.50 0.000 N/A N/A 0.000 N/A 155
7042091 7.00 0.312 N/A N/A 2.540 3.000 160
7042092 10.50 N/A N/A N/A 0.000 4.250 195
7042103 5.00 0.262 N/A N/A 2.380 1.550 160
7042105 5.00 0.262 N/A N/A 2.380 1.650 80
7042122 10.50 0.362 N/A N/A 2.640 4.250 175
7042187 12.55 0.343 13.76 11.76 3.181 4.720
74--165
