STEERING / FRONT SUSPENSION
6.6
Torsion Bars Kits - 440 Pro X Fan, 440/600/700/800 Pro X, (42.5s max. width)
Description Part Number
1/2 STD
5/8 2900183
9/16 2900184
Adjustable Torsion Bar Assembly
This assembly comes complete with all the necessary hardware to install. Slide in the aluminum block and then
attach the torsion bar assembly. Let the glide block center it self at normal ride height, then mark the glide housing
and drill through top and bottom. Insert bolt and torque to the correct amount.
Adjustable Torsion Bar Assembly - PN 2872395
Pro X Radius Rods
440/600/700/800 Pro X, radius rods have both inner and outer rod ends for adjustability.When radius rods are
installed, remove shocks and move the front suspension through its range of motion to make sure there is no
binding in the rod ends.
Upper Radius Rod
Lower Radius Rod
12.691
