ENGINE
2.11
Disassembly - Continued
4. Remove the carburetor mounting boots using
a allen wrench.
5. Remove both the cylinder head and exhaust
side fan shroud s from the engine assembly.
6. After removing the fan shrouds, take note of
the vibration dampener located between the
two intake ports.
