4.5
FUEL INJECTION
4
EFI System Exploded View
1. Electronic Control Unit (ECU)
2. Intake Air Temperature/Barometric
Air Pressure Sensor (T-BAP)
3. Crankshaft Position Sensor (CPS)
4. Fuel Injectors
5. Fuel Filter (if equipped - not shown)
6. Fuel Pump/Tank Assy.
7 Fuel Rail
8. Engine Coolant Sensor (ECT)
9. Throttle Position Sensor (TPS)
10.Throttle Body
1
2
3
4
6
7
8
9
10
4
