10.53
ELECTRICAL
10
Low Maintenance Battery Off-season
Storage
Battery voltage should be checked with a digital multitester.
Readings of 12.8 volts or less require further battery testing and
charging. See charts and Load Test.
• Remove the battery from the machine and wash the
case and battery tray with a mild solution of baking
soda and water. Rinse with lots of fresh water after
cleaning.
• Using a wire brush or knife, remove any corrosion from
the cables and terminals.
• Make sure that the electrolyte is at the proper level.
• Charge at a rate no greater than 1/10 of the battery's
amp/hr capacity until the electrolyte's specific gravity
reaches 1.270 or greater.
• Store the battery either in the machine with the cables
disconnected, or store in a cool place.
NOTE: Stored batteries lose their charge at the rate
of 1% per day. Recharge to full capacity every 30 to
60 days during a non-use period. If the battery is
stored during the winter months, electrolyte will
freeze at higher temperatures as the battery
discharges. The chart below indicates freezing
points by specific gravity.
Low Maintenance Battery Charging
Procedure
1. Remove the battery from the ATV to prevent damage from
leaking or spilled acid during charging.
2. Charge the battery with a variable rate charging output.
Charge as needed to raise the specific gravity to 1.270 or
greater.
3. Install battery in vehicle with positive terminal toward the
front. Coat threads of battery bolt with a corrosion resistant
Nyogelâ„¢ Grease (PN 2871329).
4. Route cables so they are tucked away in front and behind
battery.
5. Connect battery cables.
6. After connecting the battery cables, install the cover on the
battery and attach the hold down strap.
ELECTROLYTE FREEZING POINTS
SPECIFIC GRAVITY OF
E
LECTROLYTE
FREEZING POINT
1.265
-75
F
1.225
-35
F
1.200
-17
F
1.150
+5
F
1.100
+18
F
1.050
+27
F
WARNING
To avoid the possibility of sparks and explosion,
connect positive (red) cable first and negative
(black) cable last.
