3.14
ENGINE
GENERAL ENGINE SERVICE
Accessible Components
Following Components can be serviced or removed with the
engine installed:
• Flywheel
• Alternator (Stator)
• Starter Motor/Drive
• Cylinder Head
• Cylinder
• Piston/Rings
• Camshaft
• Rocker Arms
• Oil pump/Water Pump/Oil Pump Drive Gear
• Gear Train Components
Following Components Require Engine Removal for service:
• Counterbalance Shaft or Bearings
• Connecting Rod
•Crankshaft
• Crankshaft Main Bearings
• Crankcase
Piston Identification
Four stroke engine rings have a rectangular profile. See
“PISTON RING INSTALLED GAP” for ring installation. Use
the information below to identify pistons and rings.
Cooling System Specifications
Recommended Coolant
Use only high quality antifreeze/coolant mixed with distilled
water in a 50/50 or 60/40 ratio, depending on freeze protection
required in your area. CAUTION: Using tap water in the
cooling system will lead to a buildup of deposits which may
restrict coolant flow and reduce heat dissipation, resulting in
possible engine damage. Polaris Premium 60/40 Antifreeze/
Coolant is recommended for use in all cooling systems and
comes pre-mixed, ready to use.
Table 3-1:
ENGINE MODEL PISTON DIAMETER
EH068OLE
EH076OLE
80 mm
Table 3-2:
CONDITION
APPROX.
R
EADING (MIN.-
M
AX)
T
EMPERATURE
Hot light ON 178 - 190
215
F (108 C)
Fan Off 296 - 316
180
F (82 C)
Fan On 236 - 251
195
F (91 C)
System
Capacity
Refer To Chapter 1 Specifications
Radiator Cap
Pressure Relief
13 PSI
Radiator
Thermostat
Cylinder Head
Water Pump
Cylinder
