SPORTSMAN X2-Touring Component Locations
AWD/ADC Switch
Throttle
Ignition/Key
Instrument Cluster
Worklight
Diagnostic
Reverse
Brake Fluid Reservoir
Brake Lever
Light Control
& Run Switch
(Speedometer)
Override
X2 Rear Dump Box / Passenger Area
PVT Cover
Oil Dipstick
Front Demand
(Behind Radiator)
Front Storage
Compartment
& Rack
Gas Cap
Gear Shifter
Front Drive CV Shafts
Front Prop Shaft
(Between Transmission
and Front Gearcase)
Transmission
Muffler
Right Side View
Auxiliary Brake
Port (under access panel)
Drive Unit
Battery (Under Tank)
Rear Drive CV Shafts
(Sportsman X2 Shown)
Differential Switch
