9.16
BRAKES
4. Compress the mounting bracket and make sure the dust
seals are fully seated. Install the brake pads. Clean the disc
and pads with brake parts cleaner or denatured alcohol to
remove any dirt, oil or grease.
Installation
5. Install caliper on hub strut, and torque mounting bolts to
specification.
6. Install brake line and torque the banjo bolt to specification.
7. Install the adjuster screw and turn until stationary pad
contacts disc, then back off 1/2 turn.
8. Perform brake bleeding procedure as outlined earlier in this
chapter.
9. Install wheels and torque wheel nuts to specification. Refer
to Chapter 2.
= T
Brake Caliper Mounting Bolt Torque:
18 ft.lbs. (24 Nm)
15 ft.lbs. (21 Nm)
18 ft.lbs.
(24 Nm)
= T
Brake Line Banjo Bolt Torque:
15 ft.lbs. (21 Nm)
