6.5
CLUTCH SYSTEM
6
Engine Braking System (EBS) Exploded View
Washer
One Way Clutch Drive
Washer
Spacer
Shift Weights
Roller/Bushing
Assembly - Torque
200 ft.lbs.
Spider Lock Nut
Coil Spring
Bushing Cover
Drive Belt
Cam Assembly
Retaining Ring
Spider Assembly
Compression Spring
Clutch Shaft
Spacer Washer
Sheaves
Clutch Rollers
Bearing
Retaining Rings
