5.7
BODY / STEERING / SUSPENSION
5
Winch Installation Area
5. Remove the front cover piece by lifting up on sides of the
two locking tabs as shown. Pull the tabs out of the notches
and lift up on the cover piece.
To install the front cover place top lip of the cover into and lift
up to remove.
6. Remove the front headlights (C) or simply disconnect the
electric connector (D) before removing the front plastic
bumper.
7. Remove the remaining bolts and screws that secure the
front bumper section to the frame.
Pull Out to Remove
1. Place Lip In Groove
Groove
Lip
2. Press in Tabs
C
D
To Next Page
