1.5
GENERAL INFORMATION
1
Table 1-5: 2008 800 EFI Specifications
ENGINE
Platform Polaris Twin Cylinder
Engine Model Number EH076OLE
Engine Displacement 760cc
Number of Cylinders 2
Bore & Stroke (mm) 80 x 76.5 mm
Compression Ratio 11:1
Compression Pressure 150-200 psi
Engine Idle Speed
1150
 100 RPM
Engine Max Operating Rpm
6600 Rpm
 200 Rpm
Cooling System / Capacity Liquid - 3.6 qt/ 3.4 ltr.
Overheat Warning HOT on Instrument Cluster
Lubrication Pressurized Wet Sump
Oil Requirements / Capacity Polaris 2W-50 2 qt. / 1.9 liters
Exhaust System Dual Pipe / Silencer
Fuel System
Fuel System Electronic Fuel Injection
Fuel Pump 25L per hour at 39 PSI
Fuel Filter(s) 30 micron in Tank -
(unserviceable)
Fuel Injector(s) Bosch
EFI Controller Bosch MSE 1.1B
Fuel Capacity / Requirement 4.13 gal US / 15.6 liters
87 Octane (minimum) or 89 Oxygenated
Electrical
Alternator Output 500 w @ 6000 RPM
Lights : Pod 50 watts
Grill Two x 37 watts
Brake 8.26 watts
Tail 26.9 watts
Worklights
(If equipped)
2 x 13 watts
Ignition System DC/CDI Ignition
Ignition Timing
13
°BTDC @ 1200 RPM
Spark plug / Gap RC7YC/ .035 in. / 0.9 mm
Battery / Amp Hr Lead Acid / 30 Amp Hr
Circuit Breakers Fan 20 amp / Harness 20 amp /
ECU 15 amp / Inst. Cluster /
Voltage Regulator 6 amp
Starting Electric
Instrument Cluster Analog Speedo w/ LCD
Table 1-6: 2007 800 EFI Specifications
Drivetrain
Transmission Type Drumshift - H/L/N/Rev/Park
Transmission Capacity 15 oz. / 450ml
Front Gearcase Capacity- CH 8.97 / 265 ml
Rear Gearcase Capacity 5 oz. / 150ml
Gear Ratio : Low
Rev
High
Front Drive
Rear Drive
7.49:1
5.11:1
2.88:1
3.82:1
3.10:1
Clutch Type PVT w/ EBS
Belt 3211113
Steering / Suspension
Front Suspension / Shock A-arm / MacPherson Strut
Front Travel 8.2 in. / 21 cm
Rear Suspension / Shock Progressive Rate Independent -
Coil - over shock
Rear Travel 9.5 in. / 24.13 cm
Ground Clearance 11.25 in. / 28.6 cm
Shock Preload Adjustment
Front / Rear
Front -Non Adjustable.
Rear - Ratchet Style- Std.
Turning Radius 76 in. / 193 cm
Toe Out 0 - 1/16 in / .0 - .159 mm
Wheels / Brakes
Wheel Size / Pattern - Front 26 x 8 - 12 / 4-156
Wheel Size / Pattern - Rear 26 x 11 - 12 / 4-156
Front Tire Size 26 x 8 - 12
Rear Tire Size 26 x 11 - 12
Recommended Air Pressure Front - 5 psi & Rear - 5 psi
Brake - Front Dual Hydraulic Disc
Brake - Rear Dual Hydraulic Disc
Table 1-7: A08MN76A Clutching
Altitude
Shift
Weight
Drive Clutch
Spring
Driven Clutch Type
(Non-Adjustable)
Meters
(Feet)
0-1800
(0-6000)
A08MN76
21-74
w/
EBS
Red/Wht
7043349
w/
EBS
EBS - 1322751
1800-3700
(6000-12000)
A08MN76
21-72
w/
EBS
Red/Wht
7043349
w/
EBS
EBS - 1322751
