4.26
ELECTRONIC FUEL INJECTION
8. Remove the push rivets and screws retaining the RH rocker
panel and remove panel from the vehicle (see Chapter 5).
9. Remove the lower bolt retaining the seat belt mechanism
near the rear RH portion of the fuel tank. Once removed,
place the mechanism in the rear cargo box to keep it out of
the way.
10. Remove the (3) Torx fasteners from the rear RH fender well
and remove the fender well from the vehicle (see chapter 5).
11. Remove the (3) shift lever support bracket bolts by and
place bracket out of the way of the fuel tank, but do not
remove or cut the plastic wire harness retainer.
12. Remove the (2) tank bracket fasteners that retain the fuel
tank in the chassis. Swing the tank fastener straps clear of
the fuel tank for removal.
Set Bracket by
Shift Lever
Do Not Cut
Plastic Strap
To Next Page
