7.30
FINAL DRIVE
18. Install and tighten the large clamp using the Axle Boot
Clamp Tool (PU-48951).
19. While pulling out on the CV shaft, slide a straight O-ring
pick or a small slotted screw driver between the small end
of the boot and the shaft. This will allow the air pressure to
equalize in the CV boot in the position that the joint will
spend most of its life. Before you remove your
instrument, be sure the small end of the boot is in its correct
location on the shaft.
20. Install and tighten the small clamp on the boot using the
Axle Boot Clamp Tool (PU-48951).
Inner Plunging Joint / Boot Replacement
1. Using a side cutters, cut away and discard the boot clamps.
Axle Boot Clamp Tool
PU-48951
Axle Boot Clamp Tool
PU-48951
