3.25
ENGINE
3
ENGINE DISASSEMBLY AND INSPECTION
Cylinder Head Assembly Exploded View
Push Rods
Hydraulic Lifters
Valves
Cylinder Head
Coolant Bleeder
Springs
Spring Retainers
Rocker Arms
Retainer Locks (keepers)
Valve Spring Seats (2)
Valve Seals (2)
Head Bolts
